Z CAM E2-M4 Cine Camera - MFT
Z CAM E2-M4 Cine Camera - MFT
SKU:
Z-CAM-E2-M4
Regular price
£1,261.00 GBP ex VAT
£1,513.20 GBP inc VAT
£1,513.20 GBP inc VAT
Regular price
ex VAT
Sale price
£1,261.00 GBP ex VAT
£1,513.20 GBP inc VAT
Unit price
per
£1,513.20 GBP inc VAT
Out of Stock
Couldn't load pickup availability
- Details
- Features
- Specifications
The Z Cam E2-M4 Cinematic Camera is a 4K Ultra HD High Resolution camera. The camera comes with an iOS app for control setting and live preview options, and gigabit ethernet for data, control and live streaming. It has 13~15 stops of dynamic range (16 WDR Enabled) and its 4K @120fps, 10-bit colour for endless high quality shooting.
- DCI and UHD 4K up to 120 fps
- 13~15 stop Dynamic Range (16 WDR Enabled)
- 10-Bit Color Recording, Supports ProRes
- 4/3" WDR CMOS Sensor
- Gigabit Ethernet for data, control & live streaming
- iOS app for control setting & live preview
| CAMERA FEATURES | |
| Sensor Type: | 4/3" WDR CMOS Sensor |
| Sensor Size: | 19.0 x 13.0 mm |
| Effective Pixels: | 10.28M |
| Dynamic Range: | 13~15 Stops (Z-Log2) / 16 Stops (with WDR activated) |
| Lens Mount: | MFT mount (interchangeable) |
| Microphone: | Built-in Stereo Microphone |
| RECORDING | |
| Resolution: | 4096 x 2160 (C4K) / 3840 x 2160 (4K) 4096 x 1728 (C4K 2.4:1) / 3840 x 1620 (4K 2.4:1) 3696 x 2772 / 3312 x 2760 2704 x 1600 / 1920 x 1080 |
| Frame Rate: | 59.94 / 50 / 29.97 / 25 / 24 / 23.98 fps |
| Max Variable Frame Rate: | 120 fps for 4096 x 2160 (H.265 only) 120 fps for 3840 x 2160 (H.265 only) 150 fps for 4096 x 1728 (H.265 only) 160 fps for 3840 x 1620 (H.265 only) 160 fps for 2704 x 1600 (H.265 only) 59.94 fps for 3696 x 2772 59.94 fps for 3312 x 2760 240 fps for 1920 x 1080 (H.265 only) |
| Max Bit Rate: | H.265 / H.264 300 Mbps for 4096 x 2160 / 3840 x 2160 / 4096 x 1728 / 3840 x 1620 / 3696 x 2772 / 3312 x 2760 / 2704 x 1600 200 Mbps for 1920 x 1080 |
| Colour Bit Depth: | 10-bit (H.265) & 8-bit (H.264) |
| Video Encoder: | 12-bit ProRes Raw / 12-bit ZRAW (partial debayer) / Proxy / H.265 main 10 profile / H.264 high profile |
| Audio Format: | 16-bit 48 kHz |
| Audio Encoder: | AAC / PCM (for MOV only) |
| File Format: | MOV / MP4 |
| Record Mode: | Video / Time Lapse Video |
| SETTINGS | |
| ISO: | Auto, Manual (500 ~ 102400 / 250 ~ 51200 with WDR activated), Native ISO: 500 / 2500 (250 / 1250 with WDR activated) |
| Shutter: | Shutter Speed: Auto, Manual (up to 1/8000”) or Shutter Angle: Auto, Manual (1° ~ 360°) |
| White Balance: | Auto, Preset, Manual (2300K ~ 7500K) |
| Focus Mode: | MF / AF / CAF |
| Image: | Brightness / Contrast / Saturation / Sharpness |
| Image Profile: | Rec.709 / Z-Log2 / FLAT / HLG |
| Audio: | Audio In / Out Level |
| Time Code: | Current Time / Manual Input / External Input |
| STORAGE | |
| Media: | CFAST 2.0 |
| File System: | exFAT |
| CONNECTIVITY | |
| HDMI: | HDMI 2.0 Type A (video output up to C4K @60fps) |
| USB: | USB 3.0 Type C for camera control & data transfer only |
| COM: | DB-9 connector, supports RS-232 |
| Remote Control: | 2.5 mm jack socket (Sony LANC compatible) |
| Audio In: | 3.5 mm stereo jack socket for active microphone only, or 5-pin LEMO port for dual channel XLR microphone (requires additional XLR audio connector) |
| Audio Out: | 3.5 mm stereo jack socket |
| Wi-Fi: | 5G Wifi |
| Ethernet: | Gigabit Ethernet port for control, setting & live streaming |
| POWER | |
| Battery: | Sony NP-F series compatible (Battery not included) |
| Power Input: | DC 6.8V ~ 16.8V (2-pin LEMO socket), with LEMO connector |
| PHYSICAL | |
| Material: | Aluminum Alloy |
| Weight: | 1090g (EF mount) / 1160g (PL mount) / 930g (MFT mount) |
| Dimensions: | 91.20mm x 99.25mm x 95.60mm (without lens) |
| ENVIRONMENT | |
| Storage Temperature: | -20°C ~ 60°C |
| Operation Temperature: | 0°C ~ 40°C |
