TV Logic F-10A 10" Monitor
TV Logic F-10A 10" Monitor
SKU:
TVL-F-10A
Regular price
£2,296.48 GBP ex VAT
£2,755.78 GBP inc VAT
£2,755.78 GBP inc VAT
Regular price
ex VAT
Sale price
£2,296.48 GBP ex VAT
£2,755.78 GBP inc VAT
Unit price
per
£2,755.78 GBP inc VAT
Out of Stock
Couldn't load pickup availability
- Details
- Features
- Specifications
- What's Included
The F-10A is the new 10" field monitor with HDR capability and Full HD resolution. Designed for versatile field production applications, the F-10A offers nearly half the weight and slimmer design compared to its class size. It also supports HDMI 2.0 and HDCP 2.2 to support 4K HDR 60Hz and supports various video signals (3G HD/SD-SDI, HDMI). In addition, it provides various professional functions such as HDMI ↔ SDI conversion output, Camera LUTs, Arri Metadata Display, Waveform/Vectorscope, H/V Flip, Auto Flip, Scan and Image Overlay.
10-inch Full HD Display – A Lot More Functions in Bigger Screen!
F-10A features a large 10-inch full HD (1920 x 1080) display, while remaining powerful and light enough to take anywhere.
HDMI 2.0 and HDCP 2.2 4K HDR Monitoring
F-10A can display the 4K HDR 60Hz video so that you can see true-to-life colour and clear details.
- Excellent sharpness
- Lightweight and slim body
- Supports 3G/HD-SDI and HDMI 2.0 Interfaces
- Full HD – Native 1920 x 1080 resolution
- HDR Emulation
- HDR EOTFs of PQ, HLG and Slog3
- Various optional accessories and useful functions
| DISPLAY | |
| Size: | 10-inch |
| Resolution: | 1920 x 1080 (16:9) |
| Pixel Pitch: | 0.11475mm |
| Colour Depth: | 16.7m |
| Viewing Angle: | 160°(H) / 160°(V) |
| Luminance: | 300cd/m2 |
| Contrast Ratio: | 1,000:1 |
| Display Area (H x V): | 220.32 x 123.93mm |
| INPUTS | |
| 2x BNC: | 3G-SDI A/B Channel Input |
| 1x HDMI: | HDMI Input |
| OUTPUTS | |
| 2x BNC: | 3G-SDI Output |
| 1x HDMI: | HDMI Output |
| AUDIO | |
| Audio In: | Embedded Audio/Analog Stereo (Phone Jack) |
| FPGA Functions: | 1:1 Pixel Mapping Modes for SD/HD, 3G-SDI Level A/B, Audio Level Meter Display, Blue Only, Focus Assist, H/V Delay, H/V Flip, Key Lock, Luma(Y') Zone Check, Marker, Max Brightness On/Off, Mono, Range Error, Time Code Display, UMD, User Aspect, Various Scan Modes, Waveform/Vector, Zoom, Camera Lut |
| Calibration: | TVLogic Colour Calibration Utility, 3D LUT & Adjustable Gamma, 3rd Party 3D LUT Import |
| OTHER FUNCTIONS | |
| Remote: | GPI (RJ45) |
| USB: | Firmware update by USB memory stick |
| Ethernet: | Ethernet Control support |
| Conversion: | HDMI-to-HDMI, HDMI-to-SDI, SDI-to-HDMI, SDI-to-SDI |
| PHYSICAL | |
| Dimensions: | 258 x 154 x 29.8mm / 10.15 x 6.06 x 1.17in |
| Weight: | 1.3kg / 2.86lbs |
- 1x F-10A monitor (Mains adaptor not included. Optional purchase, part number: 2612.0207)
- 1x Camera Mount
- 1x D-Tap Adapter (Coil Type)
- 1x L-Type BNC Connector
