The FX5 is the uncompromised cinematic tool you asked for. It features 5K Open Gate, Internal RAW, and 15+-stop dynamic range. Built with a removable EVF, dedicated Timecode, and 32-bit Float audio to bridge the gap between compact agility and professional set performance.
UNCOMPROMISED CINEMATIC FREEDOM
Experience ultimate creative flexibility with 5K Open Gate and Internal RAW recording across three professional codecs. Supporting wide anamorphic ratios, this sensor allows you to capture the full picture for any delivery format, providing the flexible, high-fidelity workflow that professional work demands.
ELITE IMAGE FIDELITY IN ANY LIGHT
The new 16.6MP sensor paired with the BIONZ XR2 processor delivers a massive 15+ stops of dynamic range for stunning highlight retention and shadow detail. Featuring three Base ISO and dual-gain technology, this system ensures exceptionally clean, noise-free imagery even when shooting in the most challenging low-light environments.
PRECISION PERFORMANCE AT HIGH SPEED
Capture the most intense action with 4K at 240p and 5K at 120p recording*. A significantly faster sensor readout speed minimizes rolling shutter, while the improved low-light AF ensures critical focus is maintained during high-speed sequences, making it the most reliable tool for solo operators and B-cam professionals alike.
*available with future firmware update
MODULAR MONITORING AND ERGONOMICS
Designed for the rigors of the set, this body features a removable tiltable EVF and a larger 4-axis multi-angle LCD monitor. Whether you are stripping down for a gimbal or building up for a full production rig, the refined ergonomics and high-level monitoring support provide the tactical feedback professionals need.
SEAMLESS MULTI-CAM INTEGRATION
Bridge the gap between compact filming and full-scale production with dedicated Timecode (TC) cable compatibility. With 32-Bit Float audio recording through the handle and dual USB-C ports, this camera integrates perfectly into professional workflows, ensuring your audio and video remain perfectly synced and your data transfers are lightning-fast.
RELIABLE POWER AND CONNECTIVITY
Built for the modern cinematographers, the FX5 introduces a new high-capacity battery and enhanced Wi-Fi stability for mission-critical tasks. With 4K 60p live streaming capabilities and advanced network security, you can deliver professional-grade content directly from the field with absolute confidence and stability.
| GENERAL | |
| Camera Type: | Interchangeable lens digital camera |
|---|---|
| Lens Mount: | E-mount |
| CAMERA SECTION | |
| Type: | 35mm full frame (35.9 x 24.0 mm), Exmor RS CMOS sensor |
| Number of Pixels (Effective): | Approx. 16.6 megapixels max. |
| Number of Pixels (Total): | Approx. 18.2 megapixels |
| Optical Low Pass Filter: | Yes |
| Latitude: | 15+ stops (S-Log3) |
| Color Temperature Range: | 2000 K - 15000 K |
| Anti-Dust Function | Yes |
| RECORDING SYSTEM (MOVIE) | |
| Video Compression: | X-OCN XAVC HS: MPEG-H HEVC/H.265 XAVC S: MPEG-4 AVC/H.264 |
| Audio Recording Format: | LPCM 4ch (48 kHz 24 bit) PCM 4ch (48 kHz 32 bit float) LPCM 4ch (96 kHz 24 bit) PCM 4ch (96 kHz 32 bit float) |
| MOVIE FUNCTION | |
| Slow & Quick Motion (S&Q): | Yes |
| Proxy Recording: | Yes |
| TC/UB: | Yes |
| RAW Output: | Yes (HDMI) |
| Memory Card Slot: | SLOT A: Multi slot for SDXC (UHS-I/II compliant) memory card / CFexpress 2 Type A card, SLOT B: Multi slot for SDXC (UHS-I/II compliant) memory card / CFexpress 2 Type A card |
| FOCUS SYSTEM | |
| Type: | Fast Hybrid AF (phase-detection AF / contrast-detection AF) |
| Focus Point: | Max. 759 points (phase-detection AF) |
| Recognition Target (Movies): | Human Animal Bird |
| Other Features: | AF Subj. Shift Sensitivity (Movie) AF Transition Speed (Movie) Focus Map (Movie) AF Assist (Movie) |
| ISO Sensitivity: | ISO 320 - 409600 equivalent, AUTO (ISO 320 - 409600, selectable upper limit) |
| LCD SCREEN | |
| Type: | 8.8 cm (3.5-type) type TFT |
| Touch Panel: | Yes |
| Number of Dots (Total): | 2 764 800 dots |
| Adjustable Angle: | Opening Angles (approx.): Up 98 °, down 40 °, side 180 °, rotation 270 ° |
| CLEAR IMAGE ZOOM | |
| Movies: | Approx. 1.5x (4K), Approx. 2x (HD) |
| SHUTTER | |
| Shutter Speed: | Movies: 64 F to 1/8000 s |
| IMAGE STABILISATION | |
| Type: | Image sensor-shift mechanism with 5-axis compensation (compensation depends on lens specifications) |
| Mode: | Movie: Dynamic active / Active / Standard / Off |
| INTERFACE | |
| PC interface: | Mass-storage |
| Multi / Micro USB terminal: | - |
| USB Type-C® Terminal: | Yes (PORT1: SuperSpeed USB 10 Gbps (USB 3.2) compatible, PORT2: Hi-Speed USB 480 Mbps (USB 2.0) compatible) |
| Wireless LAN (built-in): | Yes (Wi-Fi Compatible, IEEE 802.11a/b/g/n/ac/ax (2.4 GHz band/5 GHz band/6 GHz band))*4 |
| Bluetooth: | Yes (Bluetooth Standard Ver. 5.3 (2.4 GHz band)) |
| HDMI output: | HDMI connector (Type-A) |
| Multi Interface Shoe: | Yes (with Digital Audio Interface) |
| Mic Terminal: | Yes (3.5 mm Stereo minijack) |
| XLR Audio Input: | Yes (3-pin (female) x2) |
| Headphone Terminal: | Yes (3.5 mm Stereo minijack) |
| Remote Control (Wireless): | Yes (Bluetooth remote control) |
| LAN Terminal: | Yes (2.5GBASE-T, 1000BASE-T, 100BASE-TX) |
| Functions: | FTP Transfer Func. (Wired LAN, USB Tethering, Wi-Fi) |
| VF Terminal: | Yes |
| NETWORK STREAMING | |
| Video Data Format: | MPEG-4 AVC/H.264 MPEG-H HEVC/H.265 *7 |
| Video Resolution: | 3840 x 2160 1920 x 1080 1280 x 720 |
| Audio Data Format: | AAC-LC 2ch (16bit 48 kHz) |
| Protocol: | RTMP RTMPS SRT |
| AUDIO | |
| Microphone: | Built-in, stereo |
| Speaker: | Built-in, monaural |
| LENS COMPENSATION | |
| Lens Compensation: | Shading, Chromatic Aberration, Distortion, Breathing (Movie) |
| POWER | |
| Battery: | One rechargeable battery pack NP-SA100 |
| Movies (Actual Shooting): | Approx. 105 min (LCD monitor) (CIPA standard) |
| Movies (Continuous Shooting): | Approx. 170 min (LCD monitor) (CIPA standard) |
| Internal Battery Charge: | Yes (Available with USB Type-C terminal. USB Power Delivery compatible)*9 |
| USB Power Supply: | Yes (Available with USB Type-C Terminal. USB Power Delivery compatible) |
| Power Consumption: | Approx. 7.4 W (with FE 28-70mm F3.5-5.6 OSS II lens attached) |
| WEIGHT | |
| Including Accessory: | Approx.1046 g |
| With Battery and Memory Card: | Approx. 734 g |
| Body Only: | Approx. 643 g |
| DIMENSIONS | |
| Dimensions: | Approx. 132.2 x 79.0 x 87.0 mm (from grip to monitor) Approx. 5 1/4 x 3 1/8 x 3 1/2 inches (from grip to monitor) |
| OPERATION | |
| Operating Temperature: | 0 - 40 β / 32 - 104 °F |
| Storage Temperature: | -20 to 55 β / -4 to 131 °F |
