The Rotolight Titan™ X1 reinvents the 1x1 panel; featuring best-in-class power alongside a pioneering feature-set making it ideal for both studio and location. Featuring the world's first electronic diffusion technology, SmartSoft™, electronically control diffusion, focus and spread without the need for gels, while the full-colour touchscreen display saves time on set. With powerful High Speed Sync RGB flash, built in wireless connectivity (Bluetooth/wDMX) and class leading energy efficiency, Titan X1 is the ultimate 1x1 light.
With 16.7 million colours at your fingertips and a library of over 1400 industry standard gels accessible at the touch of a button, unleash your creativity on set at a moment’s notice. With five lighting modes: CCT, HSI, RGBW, XY and Filter, unlock endless possibilities with full control over your colour. The Titan™ X1 flatters subjects in-camera and reduces the need for post-production, excelling in both CRI and TLCI performance across the entire CCT spectrum from 3,000K - 10,000K.
With a full-colour touchscreen display, preview each filter to achieve the exact colour you want at a moment’s notice. Effortlessly access key features with an easy to use interface, quick-start icons and 50 user customisable presets.
Featuring the industry’s first electronic diffusion technology, SmartSoft™, electronically
adjust your light’s diffusion, focus and spread without the need for gels. Like a 216 diffusionon an adjustable dial, SmartSoft™ provides the flexibility of a beautiful soft output and a harder light source all-in-one.
The Titan™ X1 also features Rotolight’s award-winning suite of user customisable CineSFX™ (Fire, Lightning, TV, Gunshot, Paparazzi and more); providing endless creative possibilities on set. Equipped with the first High Speed Sync RGB flash (1/8000th) with zero recycle time for more power when you need it, Titan™ X1 is also ideal for professional studio and portrait photographers.
| Technical Specifications | Lamphead |
| LED System | Rotolight PentaChromic Colour Engine™ |
| Diffuser System | Rotolight SmartSoft™ Diffusion |
| Light Aperture | 340 x 300 mm / 13.4” x 11.8” |
| Beam Angle | Electronically variable 68 degrees to 150 degrees |
| Weight | Titan™ X1 body: 6.8kg / 14.9 lbs |
| Titan™ X1 + standard yoke: 8.6kg / 18.9 lbs | |
| Titan™ X1 + pole yoke: 10.2kg / 22.4 lbs | |
| Titan™ X1 + swan-neck: 7.9kg / 17.4 lbs | |
| Dimensions | Titan™ X1 body: 400 x 145 x 360mm |
| 15.7” x 5.7” x 14.1” | |
| Titan™ X1 body + standard yoke: | |
| 510 x 155 x 510mm 20” x 6.1” x 20” | |
| Titan™ X1 body + pole yoke: | |
| 545 x 170 x 500mm 21.” x 6.6” x 19.6” | |
| Titan™ X1 + K-mount swan neck: | |
| 400 x 200 x 360mm 15.7” x 7.8” x 14.1” | |
| Handling | Pole operated yoke (pan and tilt), standard yoke |
| K-mount swan-neck with baby 16mm socket | |
| Mounting | 28mm Junior Spigot or 16mm baby spigot (K-Mount swan-neck) |
| Tilt Angle | +/- 90 Degrees |
| Lamphead DC Voltage Input | 24 V DC |
| Power Consumption | 230W Nominal |
| Lamphead Power Connection | Neutrik Speakon (Positive Pin 1+ 2+ / Negative Pin 1- 2-) |
| Battery DC Voltage Range | 20.5 V DC to 26 V DC |
| Battery Mode Light Output | 100% using Rotolight Titan™ 2 way |
| regulated 24V battery adaptor | |
| White Light | 3000K to 10,000K continuously variable Correlated |
| Colour Temperature | |
| Coloured Light | Full RGBWW colour gamut with Hue, Saturation and |
| Diffusion control | |
| Colour Temperature Tolerance | +/- 50 K (nominal), +/- 5% green-magenta (nominal) |
| CRI | 3200K >97, 5600K >95 |
| TLCI | 98 |
| Green-Magenta Adjustment | Continuously variable (full minusgreen to full plusgreen) |
| Dimming | 0 - 100 % continuous |
| Diffusion | 0 - 2 stops continuous (0%- 100%) |
| Control | Local 5 pin DMX, RJ45, Bluetooth ( via Luminair app), |
| LumenRadio, wired/w.DMX, Elinchrom Skyport | |
| Remote Device Management (RDM) | DMX setup, hour counter, and standard RDM commands |
| Flash | Skyport HSS (range 200M), up to 1/8000th sec |
| Software Interface | Firmware/software upgrade via USB-A |
| Factory Interface | Firmware installation, system configuration and calibration interface |
| Housing Colour | Black, red and silver |
| Ambient temperature operation | -20 to +45°C (-4 to 113 degrees Fahrenheit) Active Intelligent |
| Thermal Management | |
| Protection Class / IP Rating | IP20 |
| Estimated LED Lifetime (L70) | 50,000 hours |
| Estimated colour shift over lifetime (CCT) | +/- 5 % |
| Certifications | CE, FCC, UL, TÜV Rheinland , CB, cTUVus, PSE |
| Safety Testing | UL 1573:2003, UL 8750, CAN/CSA C22.2 No166-15:2015, |
| CAN/CSA C22.2 No 9 0S1-97:2011, CSA C22.2 NO. 250.13 | |
| IEC 60598-1 - Luminaire Safety | |
| EN 62471 - Photobiological safety of lamps and lamp systems | |
| Technical Specifications | Power Supply Unit |
| Power Supply Input Range | 110 to 240 V AC, 50/60 Hz |
| Power Supply Output | 24 V DC 350 watt |
| Power Input Connector | PowerCON TRUE1 |
| (Bare Ends/Shuko/Edison cables available) | |
| Power Output Connector | PowerCON TRUE1 (mains power through) |
| DC Output Connector | Female speakCON |
| (positive pin 1+ 2+ / negative pin 1- 2-) | |
| Weight | 3.6kg / 7.9 lbs |
| Dimensions | 380 mm x 135 mm x 85 mm |
| Control | On-board latching on/off switch |
| Mounting | Central K-Mount, latching K-Mount, or to |
| truss/pole via K-Mount adapter with superclamp | |
| Certifications | CE, CB, cNRTLus, TUV, FCC, PSE, UL |
