| Number of Audio Channels: | Input: 11 channels Output: 3 channels |
| Connectors: | INSTRUMENT (L/MONO, R) jacks: 1/4-inch phone type LINE IN 1 jack: Stereo miniature phone type LINE IN 2 jack: Stereo miniature phone type GUITAR/BASS jack: 1/4-inch phone type (supports high impedance) SMARTPHONE IN/OUT jack: Stereo Miniature phone type (Stereo, CTIA) MIC jack: Combo type (XLR, 1/4-inch TRS phone, phantom power DC 48 V, 6 mA max.) HEADPHONE/HEADSET jack: Stereo Miniature phone type (Stereo, CTIA) USB port: USB Micro-B type |
| Controller: | INSTRUMENT knob GUITAR/BASS knob MIC knob HEADSET MIC knob HEADPHONE/SMARTPHONE OUT knob LOOP BACK switch PAD GUITAR/BASS switch PHANTOM POWER switch BATTERY switch |
| Indicator: | POWER indicator PEAK indicator |
| Power Supply: | USB Bus Power Alkaline battery (AAA, LR03) x 4 Rechargeable Ni-MH battery (AAA, HR03) x 4 |
| Current Draw: | 170 mA |
| Battery Life for Continuous Use: | Alkaline battery: Approximately 4 hours * When setting the [BATTERY] switch to the "ON" position. * Differs depending on the conditions of use. |
| Accessories: | Leaflet "Downloading the Owner’s Manual" Leaflet "USING THE UNIT SAFELY" Lightning to USB Micro-B type cable USB Type-C(TM) to USB Micro-B type cable 3.5mm TRRS Audio cable |
| Dimensions: | 104 x 155 x 41mm / 4-1/8 x 6-1/8 x 1-5/8" |
| Weight: | 215g / 8oz |
