| ACOUSTIC & ELECTRICAL | |
| Acoustic Principle: | Pressure gradient |
| Active Electronics: | JFET impedance converter with bipolar output buffer |
| Capsule: | 1.00” |
| Polar Pattern: | Cardioid |
| Address Type: | Side |
| Frequency Range: | 20Hz - 20kHz |
| Output Impedance: | 100Ω |
| Maximum SPL: | 142 dB SPL |
| Equivalent Noise (A-Weighted): | 4dBA |
| Sensitivity: | -32 dB re 1 Volt/Pascal (25 mV @ 94 dB SPL) +/- 2 dB @ 1 kHz |
| Analogue Power Requirements: | P48 |
| Analogue Output Connection: | 3-pin XLR |
| MECHANICAL | |
| Dimensions: | 52 x 52 x 189mm |
| Weight: | 313g |
