| ACOUSTIC & ELECTRICAL | |
| Acoustic Principle: | Pressure Gradient |
| Active Electronics: | JFET impedance converter with bipolar output buffer |
| Capsule: | 1.00" |
| Polar Pattern: | Cardioid |
| Address Type: | Side |
| Frequency Range: | 20Hz - 20kHz |
| Output Impedance: | 100Ω |
| Maximum SPL: | 132dB SPL |
| Maximum Output Level: | 8.0mV (@ 1kHz, 1% THD into 1KΩ load) |
| Sensitivity: | -29.0dB re 1 Volt/Pascal (35.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz |
| Equivalent Noise Level (A-Weighted): | 4.5dBA |
| Power Requirements: | P24 and P48 |
| Output Connection: | XLR |
| MECHANICAL | |
| Dimensions: | 187 x 50 x 50mm |
| Weight: | 440g |
