| FEATURES | |
| Lens Construction: | 9 elements in 8 groups (4 aspherical lenses , 2 ED lens) |
| Nano Surface Coating: | Yes |
| Mount: | Micro Four Thirds mount |
| Optical Image Stabilizer: | YES (POWER OIS) |
| Focal Length: | f=14-42mm (35mm camera equivalent 28-84mm) |
| Aperture Type: | 7 diaphragm blades / Circular aperture diaphragm |
| Aperture Range: | F3.5(Wide) - F5.6(TELE) |
| Minimum Aperture: | F22 |
| Closest Focusing Distance: | 0.2m / 0.66ft |
| Maximum Magnification: | Approx. 0.17x / 0.34x (35mm camera equivalent) |
| GENERAL | |
| Diagonal Angle of View: | 75°(Wide) to 29°(TELE) |
| Filter Size: | φ37mm / 1.5in |
| Max. Diameter: | φ61mm / 2.4in |
| Overall Length: | Approx. 26.8mm (from the tip of the lens to the base side of the lens mount, under the condition when lens is stored) / 1.1in |
| Weight: | Approx. 95g / 3.4oz (excluding lens cap and lens rear cap) |
