| Lens Construction: | 14 elements in 9 groups (4 aspherical lenses, 1 UED lens, 1 UHR lens) |
| Nano Surface Coating: | Yes |
| Mount: | Micro Four Thirds mount |
| Optical Image Stabilizer: | Yes (POWER O.I.S.) |
| Focal Length: | 12-35mm (35mm camera equivalent 24-70mm) |
| Aperture Type: | 7 diaphragm blades / circular aperture diaphragm |
| Maximum Aperture: | F2.8 |
| Minimum Aperture: | F22 |
| Closest Focusing Distance: | 0.15m/0.49ft (at focal length 12-17mm) / 0.25m/0.82ft (at focal length 35mm) |
| Maximum Magnification: | 0.21x / 0.42x (45mm camera equivalent) (at focal length 17mm) |
| Diagonal Angle of View: | 84° (wide) - 34° (tele) |
| Dust and Splash Resistant: | Yes *Dust and Splash Resistant does not guarantee that damage will not occur if this lens is subjected to direct contact with dust and water. |
| Recommended Operating Temperature: | -10°C to 40°C (14°F to 104°F) |
| Filter Size: | φ58mm |
| Max Diameter: | φ67.6mm / 2.7inch |
| Overall Length: | Approx. 73.8mm / 2.9inch (from the tip of the lens to the base side of the lens mount) |
| Weight: | Approx. 306g / 0.67lb (excluding lens cap, lens rear cap and lens hood) |
| Standard Accessories: | Lens cap, Lens rear cap, Lens hood, Lens storage bag |
