| Lens Construction: | 18 elements in 13 groups (1 UED lens, 2 ED lenses) |
| Nano Surface Coating: | Yes |
| Mount: | Micro Four Thirds mount |
| Optical Image Stabilizer: | Yes (POWER O.I.S.) |
| Focal Length: | f=35-100mm (35mm camera equivalent 70-200mm) |
| Aperture Type: | 7 diaphragm blades / Circular aperture diaphragm |
| Maximum Aperture: | F2.8 |
| Minimum Aperture: | F22 |
| Closest Focusing Distance: | 0.85m / 2.8ft |
| Maximum Magnification: | 0.1x / 0.2x (35mm camera equivalent) |
| Diagonal Angle of View: | 34°(Wide) - 12°(Tele) |
| Dust & Splash Resistant: | Yes* *Dust and Splash Resistant does not guarantee that damage will not occur if this lens is subjected to direct contact with dust and water. |
| Recommended Operating Temperature: | -10℃ to 40℃ (14℉ to 104℉) |
| Filter Size: | φ58mm |
| Max. Diameter: | φ67.4mm / 2.65inch |
| Overall Length: | Approx. 99.9mm / 3.93inch (from the tip of the lens to the base side of the lens mount) |
| Weight: | Approx. 360g / 0.79lb (excluding lens cap, lens rear cap and lens hood) |
