| FEATURES | |
| Lens Construction: | 14 elements in 12 groups (4 aspherical lenses, 2 ED lenses) |
| Nano Surface Coating: | Yes |
| Mount: | Micro Four Thirds mount |
| Optical Image Stabilizer: | Yes (POWER O.I.S.) |
| Focal Length: | f=12-60mm (35mm camera equivalent 24-120mm) |
| Aperture Type: | 9 diaphragm blades / Circular aperture diaphragm |
| Maximum Aperture: | F2.8 (Wide) - F4.0 (Tele) |
| Minimum Aperture: | F22 |
| Closest Focusing Distance: | 0.20m/0.66ft (at focal length 12mm) / 0.24m/0.79ft (at focal length 60mm) |
| Maximum Magnification: | Approx. 0.3x / 0.6x (35mm camera equivalent) |
| GENERAL | |
| Diagonal Angle of View: | 84°(Wide) - 20°(Tele) |
| Weatherproof: | Splash/Dust/Freezeproof |
| Filter Size: | φ62mm / 2.44inch |
| Max. Diameter: | φ68.4mm / 2.69inch |
| Overall Length: | Approx. 86mm / 3.39inch (from the tip of the lens to the base side of the lens mount) |
| Weight: | Approx. 320g / 11.29oz (excluding lens cap, lens rear cap and lens hood) |
