| FEATURES | |
| Lens Construction: | 15 elements in 10 groups (1 aspherical ED lens, 3 aspherical lenses, 2 ED lenses, 1 UHR lens) |
| Nano Surface Coating: | Yes |
| Mount: | Micro Four Thirds mount |
| Optical Image Stabilizer: | No |
| Focal Length: | f=8-18mm (35mm camera equivalent 16-36mm) |
| Aperture Type: | 7 diaphragm blades / Circular aperture diaphragm |
| Maximum Aperture: | F2.8 (Wide) - F4.0 (Tele) |
| Minimum Aperture: | F22 |
| Closest Focusing Distance: | 0.23m / 0.75ft |
| Maximum Magnification: | Approx. 0.12x / 0.24x (35mm camera equivalent) |
| GENERAL | |
| Diagonal Angle of View: | 107°(Wide) - 62°(Tele) |
| Weatherproof: | Splash/Dust/Freezeproof |
| Filter Size: | φ67mm |
| Max Diameter: | φ73.4mm / 2.89inch |
| Overall Length: | Approx. 88mm / 3.46inch (from the tip of the lens to the base side of the lens mount) |
| Weight: | Approx. 315g / 11.1oz (excluding lens cap, lens rear cap and lens hood) |
