Lumens MS-10S 4K Video Soundbar
Lumens MS-10S 4K Video Soundbar
SKU:
LUM-MS-10S
Regular price
£950.00 GBP ex VAT
£1,140.00 GBP inc VAT
£1,140.00 GBP inc VAT
Regular price
ex VAT
Sale price
£950.00 GBP ex VAT
£1,140.00 GBP inc VAT
Unit price
per
£1,140.00 GBP inc VAT
Out of Stock
Couldn't load pickup availability
- Details
- Features
- Specifications
Voice-Tracking
The MS-10S features directional microphones which identify the position of participants in the room and intelligently adjust the camera to zoom onto the active speaker. This helps remote guests focus on discussions in the room.
The MS-10S features directional microphones which identify the position of participants in the room and intelligently adjust the camera to zoom onto the active speaker. This helps remote guests focus on discussions in the room.
Auto-Framing
The camera's auto-framing technology recognizes the area occupied within the room and adjusts the zoom angle to incorporate every guest. With a 120° field of view and the ability to zoom in 8x, the camera delivers superb HD or 4K output at all zoom settings.
The camera's auto-framing technology recognizes the area occupied within the room and adjusts the zoom angle to incorporate every guest. With a 120° field of view and the ability to zoom in 8x, the camera delivers superb HD or 4K output at all zoom settings.
Beamforming Microphones
MS-10S' four omnidirectional microphones have echo cancellation and noise suppression to capture every participant's voice clearly. The optional MS-EM1 expansion microphone is an ideal accessory for larger rooms. The MS-EM1 has a 3m pick-up range and is connected to the MS-10S by a 5m cable. A second expansion microphone can be added if required.
MS-10S' four omnidirectional microphones have echo cancellation and noise suppression to capture every participant's voice clearly. The optional MS-EM1 expansion microphone is an ideal accessory for larger rooms. The MS-EM1 has a 3m pick-up range and is connected to the MS-10S by a 5m cable. A second expansion microphone can be added if required.
Clear Voice Speaker
MS-10S incorporates a 20W speaker with passive diaphragm to deliver sound output that can fill small and medium sized meeting rooms. Distortion is very well controlled at higher volumes, providing clear and natural voice communications.
MS-10S incorporates a 20W speaker with passive diaphragm to deliver sound output that can fill small and medium sized meeting rooms. Distortion is very well controlled at higher volumes, providing clear and natural voice communications.
Data Bridging
MS-10S has a network port which enables it to act as a bridge to deliver Internet connectivity to the host laptop over USB. This means that the PC or Mac running the video conferencing software is no longer reliant on WiFi for streaming. All connectivity (video, audio, control and network data) is routed thru a single USB port to the MS-10S.
MS-10S has a network port which enables it to act as a bridge to deliver Internet connectivity to the host laptop over USB. This means that the PC or Mac running the video conferencing software is no longer reliant on WiFi for streaming. All connectivity (video, audio, control and network data) is routed thru a single USB port to the MS-10S.
- 4K UHD Wide-Angle Camera with Auto Framing
- Integrated voice tracking with built-in beam-forming microphones
- Optional Expansion Microphone Pod
- Voice, Audio, and Ethernet over USB
| CAMERA | |
| Sensor: | 1 / 2.8” 8.29MP CMOS |
| Viewing Angle: | 120° (D) / 107° (H) / 74° (V) |
| Lens: | Fixed lens (F2.2) |
| Resolution (Max.): | 3840 x 2160 |
| Minimum Focus Distance: | 50 cm |
| Zoom: | 8x (Max) |
| ePTZ: | Yes |
| Auto Framing: | Yes |
| Voice Tracking: | Yes |
| WDR: | Yes |
| 2D / 3D Noise Reduction: | Yes |
| Video Format: | MJPEG, H.264 |
| Presets: | 3 for IR remote control 128 for USB command |
| BUILT-IN MIC | |
| Mic Element: | 4 Mics |
| Pickup Distance: | 6 Meters |
| Frequency Response: | 50 Hz ~ 8kHz |
| Sensitivity: | -32 dBV |
| SNR: | 76 dBV |
| Echo Cancellation: | Yes |
| Noise Suppression: | Yes |
| SPEAKER | |
| Configuration: | 20W, speaker element x1 + passive diaphragm x 1 |
| Frequency Response: | 20Hz ~ 20kHz |
| Speaker Max SPL: | 95 ± 3dB 0.5m / 5W |
| Distortion: | 5% AT 5.0W / 4.47V 1kHz |
| INTERFACE | |
| DC In: | Input: 110 ~ 240 VAC, 50 / 60Hz, 1.0A max. |
| USB: | USB 3.0 type-B, compatible USB2.0 |
| RJ-45: | USB bridge to Ethernet |
| LED Indicator: | Ring, 3 color LED (Green, Blue, Red) |
| Expansion Mic Input: | Yes, with JR-45 connector |
| Remote Controller: | Yes |
| OTHERS | |
| Kensington: | Yes |
| Mount: | TV Mount, Bracket |
| Dimensions: | 23.51” x 3.55” x 2.95” / 597 x 90 x 75 mm |
| Weight: | 3.8 lbs / 1.7 kg |
