Inogeni TOGGLE ROOMS - BYOD/DYOM Switcher

Inogeni TOGGLE ROOMS - BYOD/DYOM Switcher

SKU: INO-TOGGLEROOMS
£1,095.00 GBP ex VAT
£1,314.00 GBP inc VAT
ex VAT £1,095.00 GBP ex VAT
£1,314.00 GBP inc VAT
Sale Sold out
Available to Order
View full details Liquid error (sections/main-product line 1249): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features
  • Specifications
  • What's Included
TOGGLE ROOMS provides a 4Kp60 pro-AV and unified communication system enabling users to seamlessly switch from a Room PC to laptop host, ensuring a user-friendly and efficient meeting experience.
One Cable to Own the Room
Advanced USB/HDMI devices to 2 PCs switcher
  • Attractive price
  • 4kp60 in 16:9 and 21:9 wide screen capable (HDMI)
Flexible options:
  • USB-C with power delivery 100W
  • or USB-B + HDMI
Compatible by design:
  • Crestron, Logitech, Lenovo, Poly, MAXHUB
  • Teams, Zoom…
TOGGLE ROOMS facilitates videoconferencing management without any hassles. Users can switch in a flash without waiting.
Switch 4 peripherals between 2 hosts: Redefine collaboration with Bring Your Own Device (BYOD) and Bring Your Own Meeting (BYOM) support, offering the flexibility of a push button or control pad for various meeting scenarios.
ROOM PC HOSTS THE MEETING
  • Room PC BYOD mode: In this mode, the USB and HDMI devices are routed only to the Room PC.
  • Laptop sharing and Room PC BYOD: If the user would like to send HDMI content from the laptop’s USB-C or HDMI connection to the Room PC, it is possible to do so with the HDMI SHARE output connection.
LAPTOP HOSTS THE MEETING
  • Laptops BYOM mode: In this mode, the laptop is the system that is currently selected to the main USB and HDMI peripherals. The Room PC is completely disconnected from the setup.
How it Works
TOGGLE ROOMS seamlessly integrates into a Room PC environment, allowing users to connect peripherals and charge their laptops via versatile options, such as USB-C or USB-B and HDMI for older laptop models.
This flexibility extends across various settings, from huddle rooms to large boardrooms, classrooms, and auditoriums, making it an ideal solution for unified videoconferences.
ONE CABLE SOLUTION TO TAKE CONTROL OF THE ROOM
  • 2-meter USB-C 100W cable included
  • USB-C solutions tested up to 10 meters
  • 1 or 2 monitors 4Kp60 or 21:9 widescreen capable
SWITCH BYOD/BYOM with one cable for Room PC and laptop:
Switch 4 peripherals between 2 hosts (3 USB + display): Redefine collaboration with Bring Your Own Device (BYOD) and Bring Your Own Meeting (BYOM) support, offering flexibility via a push button or control pad for various meeting scenarios.
AUTOMATIC/MANUAL HOST SWITCHING
Up to 4K/60 and 21:9 widescreen capable:
PC 1 (laptop)
  • 1x USB-C host connection (USB 3.0, DP alternate mode and power delivery 100W)
  • - OR -
  • 1x USB-B host connection and 1x HDMI 2.0 video input, up to 4Kp60
PC 2 (Room PC)
  • 1x USB-B host connection and 1x HDMI 2.0 video input, up to 4Kp60
INPUTS
  • 3x USB 3.0/2.0 devices (high-quality cameras, videobar or audio devices)
  • 1x HDMI 2.0, up to 4Kp60 for each LAPTOP and ROOM PC host
OUTPUTS
  • 1x HDMI 2.0, up to 4Kp60 for DISPLAY connection from selected host
  • 1x HDMI 2.0, up to 4Kp60 for SHARE connection from BYOD to Room PC HDMI ingest
  • 21:9 wide screen capable (HDMI)
COST-EFFECTIVE & RELIABLE SOLUTION
  • Simple to install and connect (no driver required)
  • Compatibility with leading MTR, Zoom Rooms, and pro-AV systems
  • Compatible with USB cameras, videobars and videoconferencing audio devices
SWITCHING CONTROL:
  • Controllable by RS-232
  • IP control
  • 2x GPI / relay control (PC selection: BYOD/BYOM)
  • Host switch button: Table surface-mounted button for BYOM laptop selection. Accessories are available separately.
  • OPTIONAL: INO – Host button
SUPPORT
  • Bidirectional audio system AEC works for videobars, such as Cisco, Poly, Logitech and Bose
  • 100WpPower delivery over USB-C host laptop connection
  • Multiple mounting options
  • Visual LED status
  • Switch button on the front of the devices
  • Embedded audio in USB and HDMI
ADVANCED VIDEO QUALITY
  • Automatic scaling
  • Supports multiple devices on the same host
  • Device configuration via the INOGENI MAESTRO device controller
  • BYOD/DYOM Switcher
  • 4Kp60 pro-AV and unified communication system
  • Seamlessly switch from a Room PC to laptop host, ensuring a user-friendly and efficient meeting experience
  • 4K BYOD/BYOM: 2 PCs Switcher for USB 3.0/HDMI Devices
  • Connect using One cable
  • Peace of mind (no driver required and TAA compliance)
    New Maestro device controller for easy configuration and update
  • Switch 4 peripherals between 2 hosts
  • Dimensions (W x L x H): 25.11 cm x 10.97 cm x 3.26 cm | 9.89” x 4.32” x 1.28”
  • Weight: 770 g (1.69 lb)
HOST - LAPTOP
1x USB-C Connector:

Supports USB-C DisplayPort Alternate Mode

  • DisplayPort up to 3840x2160p60 / 4096x2160p60
  • USB 3.0 (USB 3.1 Gen 1 / 5 Gbps)
  • USB 2.0 (480 Mbps)
  • Charges up to 100W
  • USB-C cable locking option
1x USB Connector: USB 3.0 Type-B
1x HDMI Connector: Up to 3840x2160p60 / 4096x2160p60
Cable locking option
HOST - ROOM PC
1x USB Connector: USB 3.0 Type-B
1x HDMI Connector: Up to 3840x2160p60 / 4096x2160p60
Cable locking option
HDMI DISPLAY OUTPUT
Resolution: Up to 3840x2160p60 / 4096x2160p60 /  21:9 wide screen capable
Connector: HDMI with cable locking option
HDMI SHARE OUTPUT
Resolution: Up to 3840x2160p60 / 4096x2160p60 /  21:9 wide screen capable
Connector: HDMI with cable locking option
USB DEVICES
Connectors: 3 x USB 3.0 Type-A ports
Power: 1.8A shared between downstream ports
VIDEO - HDMI
HDCP Compliance: Compliant with HDCP2.3, HDCP2.2 and HDCP1.4
HDMI Compliance: Compliant with HDMI2.0b, HDMI1.4 and DVI1.0
Sampling Frequency: 600MHz
Video Scaling: Crosspoint switch supports video downscaling from 4K to 1080p
Chrome Subsampling: YUV/RGB
4:4:4, 4:2:2
CEC: Ability to send CEC commands to connected HDMI display sink
AUDIO - HDMI
Audio: Audio passthrough from input to output
Formats: LPCM, Dolby Digital and DTS up to 192kHz
CONTROL
Control Options: Front button – For laptop selection
RS232
GPI
LAN
USB
IP Interface: 10/100Mbps
Supports DHCP or static addressing
IP control available through RESTAPI and Telnet connections
RS-232 Interface: 4-pos terminal block connector
Baud rates: 9600 [default], 19200, 38400 and 115200
Data bits: 8
Stop bits: 1
Parity: None
Flow control: None
GPI Interface:

4-POS terminal block connector
2x Contact-closure control

GPI:

  • Controlled by open-drain IO (short to ground) or driven IO
  • Supported voltage range: 0 to 12V max
  • Voltage threshold is 2.3V

VOUT:

  • Able to power up the led on the button of our INO-Button accessory
  • Logic-low level: 0 @ 0.5V
  • Logic-high level: 4.5 @ 5V
COMPATIBILITY
Operating System:

NO driver installation necessary!

Windows 7 and above (32/64-bit)
macOS 10.10 and above
Linux (kernel v2.6.38 and above
Compatible Videoconferencing Systems: Crestron – Flex Series
Crestron – Flex Advanced Series
Poly – Studio Room Kit with HP Mini Conferencing PC
MAXHUB – MAXHUB XCore Kit
Logitech – Tap with Rally
Logitech – Tap with MeetUp
Logitech – Rally Bar Tap room systems
Lenovo – ThinkSmart Hub Gen 2 Microsoft Teams Rooms
Lenovo – ThinkSmart Core + Controller
Lenovo – ThinkSmart Core & IP Controller Kit
Jabra – PanaCast 50 Room System
PHYSICAL DETAILS
Power Supply: 160W (85-264VAC 50/60Hz to 24V/6.67A DC)
Mounting Options: Ability to mount under the table or on a wall
Operating Temperature: 0° to 45° C / 32° to 113° F
Storage Temperature: -40° to 105° C / -40° to 221° F
Relative Humidity: 0% to 90% non-condensing
Dimensions: 25.11 cm x 10.97 cm x 3.26 cm / 9.89” x 4.32” x 1.28”
Weight: 770 g / 1.69 lb
INFORMATION
UPC Code: 051497418694
Origin: Canada
Warranty: 2 years
CERTIFICATIONS
Device Certifications: FCC, CE, UKCA, RoHS, IEC62368, RCM, SoV
Power Supply Certifications: FCC, CE, UKCA, RoHS, IEC62368, RCM, CCC, CB, EAC, VI, UL
TAA Compliant: Yes
  • 1x TOGGLE ROOMS
  • 1x USB-C to USB-C cable – 6 ft.
  • 1x USB 3.0 cable (USB-A to USB-B) – 3 ft.
  • 2x terminal block 4-pos
  • 2x mounting brackets
  • 4x M2.5 mounting screws for brackets on product
  • 4x screws for Toggle Rooms table/wall mount
  • 1x 24V/160W PSU
  • 1x power supply 85-264VAC 50/60Hz to 24V/6.67A DC
  • International adapters included in the box (USA/CA or EU/UK/AU/BIS)
  • 1x PSU mounting bracket
  • 4x screws for PSU table/wall mount
  • 4x rubber feet
