Inogeni 4K >> USB3.0 4K HDMI Capture to USB 3.0

Inogeni 4K >> USB3.0 4K HDMI Capture to USB 3.0

SKU: INO-4K2USB3
£413.33 GBP ex VAT
£496.00 GBP inc VAT
ex VAT £413.33 GBP ex VAT
£496.00 GBP inc VAT
Sale Sold out
Available to Order
View full details Liquid error (sections/main-product line 1249): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Features
  • Specifications
  • What's Included
The INOGENI 4K HDMI to USB 3.0 Converter is the most easy and reliable tool to capture uncompressed video with audio from your camera's HDMI output for your PC for recording, editing, videoconferencing and streaming applications. No driver installation is necessary and will work on all motherboards and USB 3.0 chipsets. It features a single HDMI input / USB 3.0 output, supports SD and HDTV video formats up to Ultra HD 4K (4096x2160) and most computer graphic formats.

Compact in size and powered directly from a USB 3.0 port, the converter is a practical and easy-to-use USB 3.0 capture solution. It is compatible with Windows, Mac OSX, Linux and Android operating systems, and is UVC-compliant, so it will work with all DirectShow compatible software.

The converter supports Ultra HD resolutions up to 30 fps and 1080p resolutions up to 60 fps.
All SD and HD resolution signals are converted to 4:2:2 8-bit or 4:2:0 12-bit colour spaces over USB 3.0, while all UHD resolution signals are converted to 4:2:0. The embedded audio in your HDMI signals are extracted and output as two-channel LPCM. A USB 3.0 cable is included.
How it works
The 4K2USB3 HDMI 4K to USB 3.0 professional camera converter works with any virtual meeting room software that enables USB cameras and microphones, such as Microsoft Teams, Zoom, Google Meet or BlueJeans.
Requiring no drivers and compatible with Windows, macOS and Linux laptops, the camera converter resolves all interoperability issues.
Plug & Go
INOGENI has developed numerous custom applications with our global partners. Capture, mix and switch without drivers. INOGENI makes everything work together thanks to our Pro AV camera converters.
Compatible with all HDMI cameras
This professional camera converter is fully compatible with all HDMI cameras, including professional-grade equipment such as Vaddio, Aver or Marshall cameras.
  • 4K HDMI Capture to USB 3.0
  • Supports 4K, 1080p, 1080i, 720p, 480p, and 576p video formats
  • Supports 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480 graphic formats
  • Up to Ultra HD 4K (3840/4096x2160) at 30 fps and 1080p at 60 fps
  • Outputs 4:2:0 pixel format to reduce USB 3.0 bandwidth
  • HDMI audio support
  • Digital Fluid technology - Internal frame buffers maximize frame rate with any PC
  • Hardware-based color space and sampling conversion
  • Automatic scaling and frame rate conversion (UHD upscaling not supported)
  • Customizable video processing functions
  • Image controls: Brightness, contrast, saturation and hue settings. These controls do not work when we have a 4K input.
  • Supports multiple devices on the same PC
  • Powered from USB 3.0 port
  • Compatible with Windows, OSX, Linux and Android
VIDEO INPUT
Connector & Video Resolutions:
1 x HDMI 1.4a
4K UHD (3840/4096x2160), 1440p, 1080p, 720p, 1080i, 480p, 576p, 1280x1024, 1280x960, 1280x800, 1024x768, 800x600, 640x480
Frame Rates:
60, 59.94, 50, 30, 29.97, 25, 24, 23.98 Hz for all resolutions, except 4K = 30Hz max.
Colour Space:
RGB, YCbCr, 4:4:4, and 4:2:2 (4K=RGB)
Sampling Rate:
297 MHz
Embedded Audio:
Ch 1&2 48kHz LPCM
VIDEO OUTPUT
Colour Space:
RGB, YCbCr, 4:4:4, and 4:2:2 (4K=RGB)
USB - Connector & Video Resolutions:
1 x USB 3.0 Type-B
USB - CODECs
YUY2 4:2:2 and NV12/I420/YV12 4:2:0 for USB 3.0
MJPEG for USB 2.0*
Notes for MJPEG for USB 2.0:
*Devices having serial numbers >=4K2037XXX will support MJPEG over USB 2.0. Otherwise, it will be uncompressed video.
USB - Video Scaler:
Automatic hardware based
USB - Colour Space Conversion:
Automatic hardware based
USB - Sampling Conversion:
Automatic hardware based
USB - Frame Rate Conversion
Automatic hardware based
AUDIO
Analog Audio I/O:
2-channel LPCM audio from HDMI
Audio Input Connector:
CH1&2 48kHz LPCM feed from HDMI
COMPATIBILITY
Cisco Webex Compatible:
Easily programmed macros in your Webex room device.


Native Webex implementation available in Q2 CY2022.
Intuitive interface on Webex Touch 10 or Webex Navigator.
The 4KX-PLUS is compatible with Webex Devices for multiple displays.
The 4KUSB3 is compatible with Webex Devices for one display.

Macro & Native
  • Webex Room Kit
  • Webex Room Kit Plus
  • Webex Room Kit Pro
  • Webex Room 55
  • Webex Room 70
  • Webex Room Panorama
Macro Only
  • Cisco MX700
  • Cisco MX800
  • Cisco SX80
Operating System:
No driver installation necessary.

Windows 7 and above (32/64-bit)
macOS 10.10 and above.
Linux (kernel v2638)
Minimum Host Requirements:
USB 2.0 port - We recommend USB 3.0 for uncompressed video.
4GB RAM
Intel Core i5 or equivalent
Graphic card with dedicated memory
Motherboard:
Compatible with all motherboards, Intel, Renesas, ASMedia and Fresco Logic
Supported Cameras:
Cameras and camcorders with an HDMI output
Software Compatibility:
UVC-compliant Runs with all software compatible to DirectShow, AVFoundation and V4L2

Compatible to: Teams, Zoom, Webex, Google Meet, etc.

PHYSICAL DETAILS
Dimensions (W x L x H):
8.1cm x 7.4cm x 1.9cm
3.2" x 2.9" x 0.75"
Power Supply:
Powered by USB (5V / 716mA)
Weight:
120g (0.26lbs)
Package Contents:
1 x 3ft USB 3.0 cable (Type-A to Type-B)
Operating Temperature:
0° to 45°C
32° to 113°F
Storage Temperature:
-40° to 105°C
-40° to 221°F
Relative Humidity:
0% to 90% non-condensing
INFORMATION
UPC Code:
40232164873
Origin:
Canada
Warranty:
2 years
CERTIFICATION
HDCP-Compliant:
The INOGENI device does not decrypt BD/DVD movies, satellite/cable receivers or other encrypted sources.
Certifications:
FCC, CE, RoHS, SoV, RCM, VCCI, BSMI RoHS, BSMI, CB
TAA-Compliant:
Yes
  • 4K HDMI Capture to USB 3.0
  • USB 3.0 Cable
  • User Guide
