| Model: | M200D | |
| Power: | 230W (Max) | |
| Light Head Input: | 48V/4.7A | |
| Controller AC Power Input: | 100-240V ~ 50/60Hz | |
| Controller Power Input: | DC 48V | |
| V-Mount Battery (Optional) Specifications: | 14.8V, 150Wh/26V, 270Wh | |
| Channel: | 32 (1 ~ 32) | |
| Group: | 16 groups (0~9, A~F) | |
| ID: | 1 ~ 99, OFF | |
| Colour Temperature: | 5600K | |
| CRI: | ≥96 | |
| TLCI: | ≥97 | |
| Working Environment Temperature: | -20 ~ 40 ℃ | |
| FX Light Effect: | 12 kinds within 4 types | |
| Controlling Method: | Support DMX512, 2.4G Wireless Control, Bluetooth Control, Controller | |
| Dimming Curve: | 4 types: Linear/S-Curve/Exponential/Logarithmic | |
| Mute Mode: | YES | |
| 2.4G Wireless Control Distance: | ≈60m | |
| Bluetooth Transmission Distance: | ≈30m | |
| Display Screen: | 2.4 inches | |
| Bluetooth Transmission Frequency: | 2402.00-2480.00MHz | |
| Maximum Transmit Power: | 5dbm | |
| Dimensions: | Light Body: | 425.3 x 232.3 x 141.7mm |
| Controller: | 270.4 x 123.6 x 132mm | |
| Weight: | Light Body: | ≈3.03kg |
| Controller: | ≈2.74kg | |
