FULLY PIXELATED, BEYOND LIGHTING
With EXATILE PIXEL, EXALUX introduces a new generation of multi-purpose LED tile to the film, broadcast, event and architectural markets.
EXATILE PIXEL is a fusion of a video tile and lighting fixture featuring a fully pixelated 32×32 RGBW LED matrix.
You will now be able to achieve amazing lighting effects which have never been done before.
- 1024 pixels LED tile,
- ExaChrome LED Engine (RGBW 3000K),
- CCT from 2 000K to 10 000K (Ra :95 min),
- Control Modes : CCT+G/M, X/Y, HSI, RGB, Pixel,
- Pixel Modes : P1 (32×32), P4 (16×16), P16 (8×8), P64 (4×4)
- DMX/RDM + Wireless DMX (LumenRadio CRMX™),
- Art-Net, sACN,
- V-Mount battery powered (14,4-26VDC),
- 100-240VAC input,
- 120W Power Draw,
- IPX4.
| TECHNICAL SPECIFICATIONS | |
| LED Engine: | CCT : 2 000K > 10 000K CRI (Ra) : 95 Beam : 120° Efficacy : - Illuminance: 1200 lx (@1m) |
| Dimming Range: | 0 > 100% |
| Supported Protocols: | DMX / RDM Wireless (LumenRadio CRMX™) Art-Net 4 sACN |
| Control Modes: | Manual (knob / switches) Remote (DMX / Ethernet / BLE / CRMX) |
| User Interface: | Colour TFT display, LED indicators, Backlit buttons |
| Power Consumption: | 120W Max |
| IP Rating: | IPX4 |
| Certifications: | CE, RoHS |
| Weight: | 6,35Kg |
| OPERATING CONDITIONS | |
| AC Input Voltage: | 100-240VAC |
| Storage Temperature: | Min : -30°C | Typ : 25°C | Max : +70°C |
| Operating Temperature: | Min : -20°C | Typ : 25°C | Max : +50°C |
| RADIO INTERFACE | |
| Standard / Technology: | CRMX, CRMX², W-DMX G3/G4s |
| Frequency: | 2.402 ~ 2.480 GHz |
| Antenna: | Internal, Omnidirectional, SMAI-PEX MHF® I (U.FL compatible) |
| Rx Sensitivity: | -93 dBm |
| RF Modulation: | GFSK |
| Range: | Up to 200m |
| DMX INTERFACE | |
| Protocol: | DMX512-A |
| Universe Support: | 1 |
| DMX Frame Rate: | 0,8-830Hz |
| End to End Latency: | < 5ms |
| DMX Input: | Neutrik XLR 5 pins male (1) / PoD Compliant |
| DMX Output: | Neutrik XLR 5 pins Female (1) / PoD Compliant |
| ETHERNET INTERFACE | |
| Standard: | IEEE 802.3 10/100 Mbps |
| Ports: | Neutrik EtherCON |
| USB INTERFACE | |
| Standard: | USB 2.0 Hi-Speed |
| Ports: | USB-A Host |
| POWER | |
| V-Lock: | 14.4-14.8VDC~26VDC |
| AC Input: | 100-240VAC |
