| Size: | 30.3 x 2.6 x 3.7 in (77 x 6.5 x 9.5 cm) (L x H x W) |
| Camera Motion Range: | 3 ft (90 cm) on tripod 1.5 ft (45 cm) on ground |
| Weight: | 7.3 lb (3.3 kg) |
| Mounting Options: | 3/8"-16 mounting port on bottom 3/8"-16 mounting screw on top |
| Additional Features: | - Safety lock - Foldable legs |
| Manufacturing Method: | 100% CNC Machined |
| Carrying Capacity (Horizontal): | On Ground: 50 lb (22.5 kg) On Tripod: 1 ft (30 cm) slide: 50 lb (22.5 kg) 2 ft (60 cm) slide: 35 lb (15.9 kg) 3 ft (90 cm) slide: 20 lb (9 kg) |
| Carrying Capacity (Vertical): | With Vertical Module v2, the system can lift a total of 11.4 lb (5.2 kg) in a fully vertical setup. This includes the 5.7 lb (2.6 kg) HeadPLUS v3 plus an additional 5.7 lb (2.6 kg) for your camera body, lens, batteries, and any HeadPLUS add-ons. The edelkrone Power Module (sold separately) is highly recommended for vertical setups. It allows you to remove the batteries mounted on HeadPLUS or SliderPLUS—batteries that would otherwise consume part of the system’s lifting capacity. Instead, you can power the entire system with a single external battery placed in a fixed position, not moving with the slider. This frees up valuable carrying capacity for your camera, lens, and HeadPLUS add-ons, enabling you to mount heavier gear and get the most out of your setup’s vertical motion range. |
| Sliding Speed: | 60 mm/sec max speed 0.6 mm/sec minimum speed |
| Communication and Control: | Bluetooth connection to edelkrone App for device control Bluetooth or wired connection to HeadPLUS |
| Powering: | Can be Powered with using a single NP-F battery (NP-F battery bracket already included) Can also be powered with LP-E6 batteries, (battery bracket sold separately) Can be powered with the edelkrone Power module. |
