DJI Transmission - Video Receiver
DJI Transmission - Video Receiver
£1,139.00 GBP inc VAT
£1,139.00 GBP inc VAT
Couldn't load pickup availability
- Details
- Specifications
Expected: Late September 2023
The DJI Transmission Video Receiver features DJI O3 Pro video transmission and receives video signals from the transmitter. In an environment without interference or obstruction, the video receiver provides video transmission with a maximum transmission range of 6 km*, a bitrate of up to 40 Mbps, and a minimum end-to-end latency of 70 ms. It supports multiple frequency bands in both Control and Broadcast modes and simultaneously outputs multiple video signals to display devices for remote monitoring. When used with the DJI Video Transmitter or DJI Ronin 4D, the video receiver can meet the filming requirements of mediums such as movies, TV series, advertisements, and documentaries.
*Measured with the video transmission control system in Control mode (Broadcast mode in the transmitter device disabled) in an unobstructed environment free of interference with FCC compliance.
| Weight: | Approx. 350 g (receiver only, excl. antennas) |
| Dimensions: | 127×87×26 mm (excl. antennas) |
| Operating Frequency: | 2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.250-5.350 GHz, 5.470-5.725 GHz, 5.725-5.850 GHz |
| Transmitter Power (EIRP): | 2.4 GHz: <33 dBm (FCC), <20 dBm (SRRC/CE/MIC) 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC) |
| Power Consumption: | 9 W |
| Power Supply Voltage: | 6-18 V |
| Output Voltage: | 6-18 V |
| Battery Life: | 3 hours 50 minutes |
| Output Video Format: | When used with the DJI Video Transmitter: 1080p: 23.98/24/25/29.97/30/50/59.94/60fps 720p: 50/59.94/60fps When used with Ronin 4D: 1080p: 24/25/30/48/50/60fps |
| Output Audio Format: | SDI embedded, HDMI embedded |
| Video Transmission System: | O3 Pro |
| Max Bitrate: | 40 Mbps |
| Latency: | 70 ms (1080p 60fps) |
| Video Coding Format: | H.264 |
| Max Transmission Distance: | 6 km (FCC), 4 km (CE/SRRC/MIC) - (Unobstructed, free of interference) |
| Max Bandwidth: | 40 MHz |
| Operating Temperature: | -10° to 45° C (14° to 113° F) |
