| GENERAL | ||
| Dimensions: | 144.2 x 44.4 x 33.5mm | |
| Weight: | 190.5g | |
| Number of Microphones: | 3 | |
| Touchscreen: | Size: | 2.0 inches |
| Resolution: | 556 x 314 | |
| Brightness: | 1000 nits | |
| Supported SD Cards: | microSD (up to 1 TB) | |
| Recommended microSD Cards: | Lexar Silver Plus 64GB U3 A2 V30 microSDXC Lexar Silver Plus 128GB U3 A2 V30 microSDXC Lexar Silver Plus 256GB U3 A2 V30 microSDXC Lexar Silver Plus 512GB U3 A2 V30 microSDXC Lexar Silver Plus 1TB U3 A2 V30 microSDXC Kingston CANVAS GO! Plus 64GB U3 A2 V30 microSDXC Kingston CANVAS GO! Plus 128GB U3 A2 V30 microSDXC Kingston CANVAS GO! Plus 256GB U3 A2 V30 microSDXC Kingston CANVAS GO! Plus 512GB U3 A2 V30 microSDXC Kingston CANVAS GO! Plus 1TB U3 A2 V30 microSDXC | |
| GIMBAL | ||
| Controllable Range: | Pan: | -235° to 58° |
| Tilt: | -120° to 70° | |
| Roll: | -45° to 45° | |
| Mechanical Range: | Pan: | -240° to 63° |
| Tilt: | -180° to 98° | |
| Roll: | -220° to 63° | |
| Max Controllable Speed: | 180.0°/s | |
| Angular Vibration Range: | ±0.005° | |
| CAMERA | ||
| Sensor: | 1-inch CMOS | |
| Lens: | Format Equivalent: | 20mm |
| Aperture: | f/2.0 | |
| Focus Range: | 0.2 m to ∞ | |
| ISO Range: | Photo: | 50-12800 |
| Video: | 50-12800 | |
| Low-Light Video: | 50-25600 | |
| Slow Motion: | 50-12800 | |
| Electronic Shutter Speed: | Photo: | 1/8000-4 s |
| Video (Auto): | 1/8000 s to the limit of frames per second | |
| Video (M): | 1/8000-1/4 s | |
| Max Image Size: | 16:9: | 7680×4320 |
| 1:1: | 6144×6144 | |
| Zoom: | Photo: | 7680×4320: 2x |
| Video: | 1080p: 4x 3K: 4x 4K: 4x | |
| UVC & DP: | 4K: 4x | |
| Livestream: | 1080p: 4x | |
| Low Light / Slow Motion / Timelapse: | Not available | |
| Still Photography Modes: | Single Shot: | Approx. 37 MP |
| Countdown: | Off/0.5/1/2/3/5/10s | |
| Panorama: | 180°, 3x3 | |
| Normal Video: | 4K (16:9): | 3840x2160@24/25/30/48/50/60fps |
| 1080p (16:9): | 1920x1080@24/25/30/48/50/60fps | |
| 3K (9:16): | 1728x3072@24/25/30/48/50/60fps | |
| 1080p (9:16): | 1080x1920@24/25/30/48/50/60fps | |
| Slow Motion: | 4K (16:9): | 3840x2160@100/120/200/240fps |
| 1080p: | 1920x1080@120/240fps | |
| Hyperlapse: | 4K/1080p@25/30fps: | Auto/x2/x5/x10/x15/x30 |
| Timelapse: | 4K/1080p@25/30fps: | 4K/1080p@25/30fps Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60s Duration: 5/10/20/30 mins, 1/2/3/5/10/∞ hours |
| Motionlapse: | 4K/1080p@25/30fps: | 4K/1080p@25/30fps Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40/60 s Duration: 5/10/20/30 mins, 1/2/3/5/10 hours Supports setting four positions |
| Low-Light Video: | 4K (16:9): | 3840x2160@24/25/30fps |
| 1080p: | 1920x1080@24/25/30fps | |
| Max Video Bitrate: | 180 Mbps | |
| Supported File System: | exFAT | |
| Photo Format: | JPEG/DNG/JPEG+DNG | |
| Video Format: | MP4 (HEVC) | |
| Built-in Storage Capacity: | The camera has 107 GB of built-in storage. The storage capacity can be expanded by inserting a microSD card. | |
| Audio Output: | 48 kHz 16-bit; AAC | |
| BATTERY | ||
| Type: | Li-ion | |
| Capacity: | 1545 mAh | |
| Energy: | 11.95 Wh | |
| Voltage: | 7.74 V | |
| Operating Temperature: | 0° to 40°C (32° to 104°F) | |
| Charging Temperature: | 5° to 45°C (41° to 113°F) | |
| Operating Time: | 240 mins Tested at room temperature of 25° C (77° F) and 1080p/24fps (16:9), with Wi-Fi off and screen off. This data is for reference only. | |
| Charging Time: | 18 mins to 80%; 32 mins to 100% Tested in a laboratory environment with the DJI 65W Portable Charger (sold separately). | |
| CONNECTION | ||
| Wi-Fi Operating Frequency: | 2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz | |
| Wi-Fi Protocol: | 802.11 a/b/g/n/ac/ax | |
| Wi-Fi Transmitter Power (EIRP): | 2.4GHz: | < 20 dBm (CE/SRRC/MIC) |
| 5.1GHz: | < 23 dBm (SRRC) < 20 dBm (CE) | |
| 5.8GHz: | < 23 dBm (SRRC) < 14 dBm (CE) | |
| Bluetooth Operating Frequency: | 2.400-2.4835 GHz | |
| Bluetooth Transmitter Power (EIRP): | < 14 dBm | |
| Bluetooth Protocol: | BLE 5.4, BR/EDR | |
