CoreSWX VoltBridge Enabled Fleet Micro 3A Digital Quad Charger (V-Mount)
CoreSWX VoltBridge Enabled Fleet Micro 3A Digital Quad Charger (V-Mount)
£1,445.63 GBP inc VAT
£1,445.63 GBP inc VAT
Couldn't load pickup availability
- Details
- Features
- Specifications
- What's Included
Four independent charge bays on the V-mount Mach4 Micro Four-Position Battery Charger from Core SWX can charge four 98Wh batteries in less than 1 hour and 40 minutes, thanks to its 4A quick charge current. Adaptive charge control technology improves battery longevity by 30% by taking into account the age, cycle count, and last full charge of your batteries. When in charge mode, the device monitors the pack for feedback and adjusts as needed so as not to overcharge the battery and to account for changes in cell performance over time. Red and green LED indicators and an LCD screen show the charging status for easy monitoring. The unit is compatible with the cloud-based VoltBridge Mesh monitoring platform to supervise your battery's status via a single IP connection.
On top of this battery management functionality, the Mach4 Micro features SafeFly discharge mode. When the AC main power is disconnected, the charger will add standalone discharge to reduce the connected batteries to under 30% power for safe transport. Enabling this feature is as simple as touching the onboard button or using the compatible Voltbridge app. The device supports 90 to 240 VAC power via its IEC connection for worldwide use. A recessed carry handle makes traveling with the Mach4 Micro a breeze, and its aluminum construction ensures a durable but lightweight design.
- Four position charger, 4A Simultaneous rapid charge, Adaptive Charge Control
- Four independent charge bays with Simultaneous charging
- Approximately 90min. charge time for four 98Wh batteries
- Red and green status LEDs with diagnostic LCD and Test function
- Compatible with Voltbridge and Voltbridge Mesh Enterprise
- 90-240 VAC worldwide compatible input voltage
- Weighs 5 lb
- Recessed carry handle
- Quick Charge Current: 4A Simultaneous
- Discharge Current: Up to 2A per channel
- LCD: 4x20 Character Backlit
- Size: 8.9” x 3.35” x 12.4”
- Weight: 5lbs.
- Input Voltage: 90-240VAC 50/60Hz
| Mount / Series Type | V-Mount |
| Number of Battery Bays | 4 |
| Output Connector | C13 IEC Male XLR 4-Pin Female |
| AC Input Power | 90 to 240 VAC, 50 / 60 Hz |
| Power Output | V-Mount: VDC at 4 A |
| Multi-Bay Charging Modes | Simultaneous |
| Recharge Time | 90 Minutes (98 Wh Batteries) |
| Indicator | LCD Display, LED |
| Dimensions | 12.4 x 8.9 x 3.4" / 315 x 226.1 x 86.4 mm |
| Weight | 5 lb / 2.3 kg |
- Core SWX Mach4 Micro Four-Position Battery Charger (V-Mount)
