| OPTICAL SPECIFICATIONS | ||
| Image Size: | Full Frame | |
| Angle of View: | Horizontal: | 74° - 19° 20' |
| Vertical: | 53° - 13° | |
| Diagonal: | 84° - 23° 20' | |
| Lens Construction: | 23 Elements / 18 Groups | |
| Special Optics: | 4 x UD, 2 x GMo aspherical, 1 x replica aspherical | |
| Special Features: | Iris Ring (Video) | |
| Number of Diaphragm Blades: | 11 | |
| Minimum Aperture: | 22 | |
| Closest Focusing Distance: | 0.45m (at 24mm) 0.45m (at 105mm) | |
| Maximum Magnification: | 0.08x (at 24mm) 0.29x (at 105mm) | |
| Control Ring: | Yes | |
| Image Stabilizer (OIS): | 5.5 | |
| Image Stabilizer (IBIS x OIS): | 8.0 | |
| AF Actuator: | Dual Nano USM | |
| Coatings: | ASC, Super Spectra | |
| Fluorine: | Front | |
| PHYSICAL SPECIFICATIONS | ||
| Dust / Moisture Resistance: | Yes | |
| Exterior Coating: | - | |
| Filter Diameter: | 82mm | |
| Max. Diameter x Length: | 88.5 x 199mm | |
| Weight: | 1430g | |
