| OPTICAL FEATURES / SPECIFICATIONS | |
|---|---|
| Image size | Full Frame |
| 35mm Film Equivalent Focal Length (mm) | 135mm |
| Angle of View (Horzntl, Vertl, Diagnl) | 15º, 10º, 18º |
| Lens Construction (Elements/Groups) | 17 / 12 |
| Special Optics | 3 x UD |
| Special features | Lens Function buttons |
| No. of diaphragm blades | 9 |
| Minimum Aperture | 22 |
| Closest Focusing Distance (m) | 0.7 |
| Maximum Magnification (x) | 0.26 |
| Control Ring | Yes |
| Image stabilizer OIS*1 | 5.5 |
| Image stabilizer IBIS x OIS*1 | 8 |
| AF actuator | Nano USM |
| Coatings | ASC, Super Spectra |
| Fluorine | Front |
| Physical Specifications | |
| Dust/moisture resistance*3 | Yes |
| Filter diameter (mm) | 82 |
| Max. diameter x length (mm)*2 | 89.2 x 130.3 |
| Weight (g) | 935 |
| Accessories | |
| Lens cap | E-82 II |
| Lens hood | ET-88B |
| Lens case/pouch | LP1319 |
| Rear cap | Lens Dust Cap RF |
| Extender Compatibility | Not Compatible |
| Footnote | |
| 1 Tested under CIPA standards 2 Lens dimensions when in retracted state 3 Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause slight abrasion of the camera mount. This in no way effects either the lens or camera performance. | |
