The ultimate film lighting tube for TV, cinema, and photography.
Film Lighting Tube | Titan Tube was especially designed for the Film, Broadcasting and Cinema industries. Optimized for an ultra-high TLCI, a very high CRI and peak brightness, colors as well as Hue, Saturation and Intensity can be set directly on the tube. In addition, the Titan Tube now accepts wired DMX via a special power/data combination cable.
***ART7 AsteraBox CRMX needed to control TitanTube with the Astera App**
- Talkback+: Detect all available lights, set them up, check their status, configure DMX addresses and DMX profiles.
- Seamless Runtime: Set the length of your production and be sure that your lights won`t run out while still getting the maximum brightness.
- TruColor Calibration: Individually calibrated lights lead to 100% color consistency and exact color reproduction of color temperature and filter gels.
- Effects: Quickly build programs out of colors and effects, trigger them or make them match a beat.
- Flicker Free: Scrambled PWM technology to avoid flickering when filming.
- Green/Magenta Correction: Adjust green/magenta during content creation to reduce postproduction work.
- Scheduled StandBy: Switch lights into power-saving standby and schedule them to wake up when the production starts.
- Dynamic PowerBoost: This exclusive feature makes the light able to display the maximum brightness at all time and intensify non-white colors.
- Emergency Lights: Switches to white light when AC power is cut to keep your event save
- Anti-Theft: The lights give visual and audible alarm and send notification to the AsteraApp if they are being moved during an event.
- DJ Feature: Auto BPM analyzes the beat and matches programs to it, flash buttons can trigger special effects while being held down.
- Other Features: The AsteraApp™ is packed with many additional items and new features are frequently added via software update.
| Order Code | FP1 | FP1-BTB |
|---|---|---|
| LED Engine | Titan LED Engine | |
| Colors | RGBMintAmber | |
| Total LED Power | 72 W | |
| LED Power draw | 48 W | |
| Luminous Flux 3200K | 2535 lm | |
| Luminous Flux 4000K | 2900 lm | |
| Light Output 3200 K @ 1m | 708 lx | |
| Light Output 4000 K @ 1m | 785 lx | |
| CRI(Ra)/TLCI 3200-6500K* | ≥96 | |
| Beam Angle | 135° x 115° | |
| Field Angle | 175° x 160° | |
| Strobe | 0-25 Hz | |
| Pixel | 16 | |
| Battery Runtime | Up to 20 hours | |
| Battery Runtime Max Brightness | 1h 45min | |
| Battery Lifetime | 70 % after 300 cycles | |
| Charging Time (nominal) | 3 hours | |
| DC Input | 24 VDC – 2 A | |
| DC Connector | 5.5 mm x 2.1 mm | |
| AC Input | No | |
| AC Connector | No | |
| Wired DMX | Yes | |
| CRMX Receiver | Built-in | |
| BluetoothBridge BTB | No | Yes |
| Wireless Protocols | CRMX, UHF, Bluetooth | CRMX, UHF, Bluetooth, WiFi |
| Wireless Range | CRMX/UHF up to 300 m / 330 yds | CRMX/UHF up to 300 m / 330 yds Bluetooth up to 3 m / 3.3 yds |
| Infrared Control | Yes | |
| ControlSync | No | |
| TouchSlider | No | |
| Housing Material | Polycarbonate, metal end caps | |
| IP Rating | IP65 (only with FP1-SP) | |
| Ambient Operating Temperature | 0 – 40 °C / 32 – 104 °F | |
| Weight | 1.35 kg / 3 lbs | |
| Dimensions | Ø43 mm x 1035 mm/ Ø1.7” x H40.7” | |
| Mounting Options | 2x M5 thread, 2x Holder (with 2x M5 and 1x 1/4"-20UNC thread), 1x TubeStand | |
- 1 x Titan Tube (FP1)
- 2 x TubeHolder (AX1-H)
- 1 x TubeStand (AX1-STD)
- 2 x Eyebolt (FP1-EBLT)
- 1 x DC Socket Cover (FP1/2-SP)
