Astera Pluto Fresnel Kit

Astera Pluto Fresnel Kit

SKU: AST-ASPAF80-KIT
£2,702.70 GBP ex VAT
£3,243.24 GBP inc VAT
ex VAT £2,702.70 GBP ex VAT
£3,243.24 GBP inc VAT
Sale Sold out
Out of Stock
View full details Liquid error (sections/main-product line 1249): Could not find asset snippets/icon-arrow.liquid
  • Details
  • Specifications
  • What's Included
EXPECTED RELEASE: SEPTEMBER 2023
Kit of 2 Pluto Fresnels with Lens, Barndoor, Yoke, Yoke Base, TVMP Adapter, Track Handle and power supplies stored in a durable protective plastic case.
Astera’s PlutoFresnel is an exceptional solution for film, studio, and event lighting. PlutoFresnel boasts an impressive output comparable to a traditional 300W Tungsten Fresnel. With a beam angle of 15° to 60° without color fringing, wireless and wired DMX control, these lights offer impressive performance while consuming only 80W. Easy to mount and adjust with removable handles and YokeBases, they enhance creativity and productivity on any set.
Built-In Battery - 3 hours on MAX Runtime
Unlike traditional Fresnels, this light has a built-in battery that lasts 3 hours displaying white colors on MAX Brightness. When a longer operation is needed, you can set the Seamless Runtime setting up to 20 hours. For longer installations, PlutoFresnel can be connected to 24V DC power.
External Battery Option - With RuntimeExtender
For a longer operational time, a RuntimeExtender with V-Mount or Gold Mount battery can be connected. The light’s Yoke is designed to attach this device easily. External batteries can charge the light’s internal battery. You can use either 14.4V or 26V batteries.
Zoomable Fresnel
This next generation Fresnel lens works in conjunction with a light pipe that is built into the fixture. It creates an even beam with steep fall-off and no chromatic aberration or color fringing. The manual zoom ranges from 15° – 60° and allows it to be opearated as spotlight, washlight and anything in between.
Barndoor
Included with each light is a eight-leave Barndoor. Its specific design leads to ultra-clean cuts; the edges stay razor sharp when shaping your beam.
Open Face
For additional versatility, the Fresnel lens can be slid out after opening its lock. This gives you a wider beam with even crisper shadows.
Projection Lens - Coming Late 2023
A custom-built projection lens with 16°-36° zoom, manual focus and 4 shutters. Turn your LeoFresnel into a profile that also allows you to insert E size Gobos.
Order Code: AF80
LED Engine: Titan LED Engine
Colours: RGBMintAmber
Total LED Power: 105 W
LED Power Draw: 80 W
CRI (Ra) / TLCI 3200 - 6500K: ≥96
Beam Angle: 15° – 60°
Field Angle: TBD
Strobe: 0 – 25 Hertz
Pixels: 1
Battery Runtime: up to 20 hours
Battery Runtime (Max. Brightness): 3h
Battery Lifetime: 80 % after 400 cycles
DC Input: 24 VDC, 80W
DC Connector: 5.5 mm x 2.1 mm
Power Consumption (Max.): 80W
Wired DMX: Yes (via FP3-DTL / PWB-2-86)
CRMX Receiver: Built-in
BluetoothBridge BTB: Built-in
Wireless Protocols: CRMX, UHF, Bluetooth, WiFi, RDM
Wireless Range: CRMX/UHF Up to 300 m / 330 yds Bluetooth Up to 3 m / 3.3 yds
Infrared Control: Yes
ControlSync: No
TouchSlider: Yes
Housing Material: Polymer & Metal
IP Rating Unwired: IP55 (only with PB15-PLG)
IP Rating Wired: IP55 (only with PWB-CAB-0.2/-1.5/-5/-10/-15)
Ambient Operating Temperature: 0 – 40 °C / 32 – 104 °F
Weight (with AF80-FL, AF80-BD): 4.637 kg / 10.22 lbs
Weight (with AF80-FL, AF80-BD, AF80-YK, 2x AF80-YKB, AF80-THD): 6.493 kg / 14.31 lbs
Dimensions: 281.9 mm x 153.5 mm x 161.8 mm / 11.1" x 6.0" x 6.4"
Dimensions (with AF80-YK, 2x AF80-YKB): 281.9 mm x 244.7 mm x 323 mm / 11.1" x 9.6" x 12.7"
Mounting Options: 4 x AirlineTracks, 1/2" hole, 3/8" thread, 1 x BrickMount (PB15-BMO)

Kit of 2 PlutoFresnel with Lens, Barndoor, Yoke, YokeBase, TVMP Adapter, TrackHandle and Power Supplies stored in a durable protective plastic case with wheels and handle.
